MPC Enters ‘Terminator: Genysis’ & ‘The Martian’ into AEAF

MPC has entered two projects into the AEAF Awards from their feature film team, ‘Terminator: Genysis’ & ‘The Martian’.

The team's work on 'Terminator' includes more than 300 photoreal shots, lead by VFX Supervisor Sheldon Stopsack and VFX Producer Chad Nixon. The project involved creating Endoskeletons, an explosive battle at LAX, various CG set extensions and FX work – but by far the biggest challenge for MPC’s team was re-building the digital Arnold Schwarzenegger T-800 character exactly as he was in 1984, to play in 1-1 recreations of scenes from the original Terminator movie and a brutal showdown between the young and old character at the LA Observatory.

AEAF 16 - 17 August 2016
Register to attend AEAF 2016

MPC’s work began on set where Gary joined the filmmakers to capture principal photography. For accurate and realistic recreation of the CG character, it was crucial to get the best coverage from the shoot including texture photography, set measurements and HDRI capture.

For the model build, a scan of an original cast taken of actor Arnold Schwarzenegger in 1984 was used along with a huge library of reference video and images. Around 220 different face shapes were built as a base for facial performance. The team then completed a MOVA performance capture with Arnold Schwarzenegger himself. This set of defined FACS [Facial Action Coding System] shapes were used to refine what had been built up until that point.

Performances of specific dialogue were captured, giving the animation team a strong base, which they used as a reference to hand animate the digital double’s final facial performance on top. The subtleties of the team’s facial animation work, was a crucial element in maintaining believability when bringing the character to life once again.

For the character’s skin, MPC’s techAnim team ran additional cloth solvers for more realistic skin behaviour and the rigging team created controls for fine details such as blood flow tension and compression. A new physically based rendering approach was used to take advantage of recent path tracing techniques, which supported multilayer scattering for the skin shading.

MPC’s proprietary fur tool furtility was used for the double’s hair. Another challenge was achieving the complex muscle behavior of Arnold’s body, not only because a full dynamic and realistic human muscular system was required. It also had to match the unmistakable appearance of Arnold Schwarzenegger at that time. In total, the CG character was built and refined over a period of 11 months.

MPC also worked on the visual effects for the high action LAX battle sequence. The production art department delivered concept art showing aerial views of a destroyed LAX, with an enclosed camp and huge aircraft hanger. From this, MPC’s team extended the practical set build, and individual components of the Camp including sections of wall, fuel cells, towers and turret guns were recreated and placed around the CG environment . It was important that the location was recognisable as LAX, which meant preserving the famous landmarks such as the LAX tower and Theme Building / Encounter restaurant were kept in place.

'The Martian'

To get started on ‘The Martian’, MPC joined the project during pre-production, working with VFX supervisor Richard Stammers to develop the look for the Martian surface. By referencing the archives of NASA’s Mars missions, the team collated and balanced the best references to match the shooting location in Wadi Rum in Jordan and, from there, turned this environment, made famous in ‘Lawrence of Arabia’, into something more alien.

A key component of the work was selectively grading the sky from blue to the bronze and landscape to the butterscotch tones of the director’s preferred Martian images. Conventional tools did not give the team enough control for this, so MPC 2D Supervisor Lev Kolobov created a specific tool in Nuke called EarthToMars, or ETM. The tool would detect any traces of blue from shots with the Jordan skyline and remove it using Lev’s algorithms that preserved the haze detail in the mountains while simultaneously re-grading the reflected skylight.

MPC’s environments team then created a full-CG version of the Wadi Rum Hab environment using high-resolution photography taken on location in Jordan, adding extra rocks, craters, mountain ranges and a view of a distant Olympus Mons to create a grander landscape. Loosely based on NASA imagery, director Ridley Scott wanted to add more drama to the vistas in the form of fast-moving ice and dust clouds, and drifting surface dust devils. The team created these with Houdini and Maya CG fluid simulations combined with practical elements of pouring salt and dry ice elements. The finished environment was used both to enhance the unit photography from Jordan, and to create a matching background for the greenscreen plates shot on stage in Budapest.

Each astronaut wears a protective helmet with reflective Perspex and gold visor pieces. In order to integrate them effectively into the environment, they would need realistic reflections for the visors. For most shots, the actors were filmed without the visors in their helmets and MPC added CG visors in post by tracking the helmets and rendering reflected versions of the CG environment. To complete the effect, the astronauts’ bodies were tracked and CG versions of them rendered to create correct reflections of their actions in the visors.

The gigantic dust storm that strands the character Watney on Mars entered the story using the MPC FX team’s fluid simulations to create the approaching storm front. Once the storm envelops the astronauts, the effect was realized largely with practical effects on set. Huge fans blew smoke and vermiculite particles across the stage. The team added layers of smoke, particles and FX simulations to the live-action plates to enhance the density of the storm, increase its ferocity and balance the look across the sequence.  www.aeaf.tv
